Description
The
160mm underground drainage access plug from Aquaflow provides a removable maintenance point within compatible 160mm underground drainage systems. The
Aquaflow 150MMUGAPL access plug features a screwed removable cap and spigot-ended connection, making it a practical
160mm screwed access plug,
160mm rodding access plug and
spigot ended drainage access plug for inspection, cleaning and maintenance. Designed for compatible 160mm underground drainage pipework and fittings, this access plug allows a drainage opening to remain closed during normal service while still providing future access when the system needs inspecting or clearing.
160mm Underground Drainage Access Plug
The
160mm underground drainage access plug is used to create a serviceable closure within compatible 160mm underground drainage systems. Unlike a permanent blanking plug, the screwed cap can be removed when access to the drainage run is required. This makes the
160mm underground drainage access plug particularly useful for planned inspection and maintenance points.
Choosing a 160mm Underground Drainage Access Plug
Use this
160mm underground drainage access plug with compatible 160mm underground drainage sockets and fittings where a removable access point is required. The fitting should remain accessible after installation. Avoid positioning the removable cap where it will later be permanently obstructed by concrete, landscaping, structural work or other drainage components.
Aquaflow 150MMUGAPL Access Plug
The
Aquaflow 150MMUGAPL access plug is the genuine product reference used for this 160mm underground drainage fitting. Aquaflow is Kalsi Plastics’ drainage brand and includes 110mm and 160mm underground drainage systems for domestic and commercial foul-water and surface-water applications.
Aquaflow 150MMUGAPL Access Plug for Maintenance
The
Aquaflow 150MMUGAPL access plug provides access without requiring a section of pipework or a complete fitting to be dismantled. When maintenance is required, the screwed cap can be removed to allow inspection, cleaning or suitable rodding of the drainage run before being refitted.
160mm Screwed Access Plug
This
160mm screwed access plug uses a removable threaded cap rather than permanently sealing the drainage opening. The
160mm screwed access plug is therefore useful where future drainage maintenance needs to be considered at the installation stage.
Removable Cap on the 160mm Screwed Access Plug
The removable cap allows the drainage system to remain closed during normal operation while retaining a point that can be opened when inspection or cleaning is needed. After maintenance, make sure the cap is refitted correctly and securely before the drainage system is returned to normal use.
160mm Rodding Access Plug
The fitting can also serve as a
160mm rodding access plug where the drainage layout and installation provide a suitable route for maintenance equipment. A correctly positioned
160mm rodding access plug can reduce the amount of pipework that needs to be disturbed when a drainage run needs clearing or investigating.
Planning a 160mm Rodding Access Plug
When planning a
160mm rodding access plug, consider the direction of the pipe run and make sure there is enough surrounding space to remove the screwed cap and use the access point effectively. An access plug is intended as a maintenance fitting and should not be treated as a substitute for a full inspection chamber where chamber access is required.
Spigot Ended Drainage Access Plug
The Aquaflow fitting is a
spigot ended drainage access plug designed to fit into a compatible 160mm underground drainage socket. The spigot-ended configuration means the fitting does not provide its own receiving socket. Instead, the
spigot ended drainage access plug is inserted into a compatible socketed pipe or fitting within the drainage system.
Installing a Spigot Ended Drainage Access Plug
Before installing the
spigot ended drainage access plug, check that the receiving socket and seal are clean and free from grit, damage and loose material. Where required by the drainage system, use suitable drainage lubricant on the ring-seal joint and insert the fitting squarely into the socket without damaging or displacing the seal.
Inspection and Maintenance Access
Access points are useful throughout underground drainage systems because they allow installers and maintenance teams to inspect or clear pipework without unnecessary excavation or dismantling. The removable screwed cap makes this fitting suitable for planned access points on larger 160mm drainage installations.
Foul Water and Surface Water Drainage
Aquaflow’s underground drainage range is designed for foul-water and surface-water drainage applications. This access plug can therefore form part of a compatible 160mm gravity drainage layout used around domestic, commercial and groundwork projects.
BS EN 1401 Underground Drainage System
The Aquaflow underground drainage system is manufactured for underground gravity drainage applications, and the existing Speedy product identifies the fitting as part of the Aquaflow EN1401 system. BSI certification records also specifically include a
160mm Access Plug Set under BS EN 1401-1 for PVC-U non-pressure underground drainage and sewerage systems.
PVC-U Underground Drainage Fitting
BS EN 1401-1 covers PVC-U piping systems for non-pressure underground drainage and sewerage. PVC-U provides a lightweight and corrosion-resistant material for underground drainage systems while allowing compatible components to be assembled using established drainage jointing methods.
160mm Drainage Access Plug Applications
The
160mm underground drainage access plug can be useful for:
- 160mm underground drainage systems
- Foul-water drainage
- Surface-water drainage
- Drain inspection access
- Drain cleaning and maintenance
- Rodding access where appropriate
- Closing compatible socket openings
- Domestic groundwork
- Commercial drainage installations
- Drainage repairs and alterations
Access Plug vs Socket Plug
An access plug and a plain socket plug perform different jobs. A standard socket plug is primarily intended to close a compatible drainage socket. An access plug includes a removable screwed cap so that the drainage system can be reopened later for inspection or maintenance. Choose this fitting where future service access is required rather than simply blanking an unused socket.
160mm Underground Drainage Access Plug Key Features
- Genuine Aquaflow underground drainage fitting
- Product reference: 150MMUGAPL
- Nominal size: 160mm
- Screwed removable access cap
- Spigot-ended connection
- Fits a compatible 160mm underground drainage socket
- Suitable for inspection and maintenance access
- Suitable for rodding access where the installation allows
- Suitable for compatible foul-water and surface-water drainage
- Part of the Aquaflow underground drainage system
- EN1401 / BS EN 1401-1 underground drainage system
